Elevator Door Protect Sensor applies to leveling inductor device It uses to control acutually position of DOOR elevator in movement.
Customers check its function and parameters in accordance with its specification and type to ensure its performance matching with the elevator actual state.
Elevator Magnetic Door Zoon Sensor Specification
Main Features
| ZG Type | CTB-PC-DS609A | CTB-PC-DS609B | CTB-PC-DS618B |
| Size L*W*H mm | 19.5*11.7*2000 | 19.5*11.7*2000 | 19.5*11.7*2000 |
| Voltage | 90-250V/50-60hz | 90-250V/50-60hz | 90-250V/50-60hz |
| temperature range | (-30+70 ) | (-30+70 ) | (-30+70 ) |
| Respones Time | <40 m/s | <40 m/s | <40 m/s |
| Power | <10 W | <10 W | <10 W |
| Number of diodes | 17 | 32 | 32 |
| Maximum beams | 96 | 154 | 154 |
| Mimnum beams | 33 | 96 | 96 |
| Lowest beam | <20 mm | <20 mm | <20 mm |
| IP Rating | 54 | 54 | 54 |
| Highest beam | 1850 mm | 1850 mm | 1850 mm |
| Distance diodes | 118 | 59 mm | 59 mm |
| Detecting distance | 0-4000mm | 0-4000mm | 0-4000mm |
| Cable Length m | 3.5 | 3.5 | 3.5 |
| Replace Brand | WECO A | WECO A | WECO A |
